Nihon Kohden Mainstream ETCO2 Sensor

Nihon Kohden Mainstream ETCO2 Sensor

Place of Origin: Shenzhen, China

Payment Terms: 100% T/T, Paypal, Alipay

Shipping Method: DHL, TNT, EMS, Fedex, UPS, by sea

Delivery Time: 1-3 days for sample,7-14 days for big order after payment

Technical Specification

Sample Flow Rate	Range:50-150 ml/min; Accuracy:±20% ; Default: 75 ml/min
Principle of Operation	Non-dispersive infrared, dual wavelength, no moving parts
Initialization Time	Capnogram displayed in less than 4 seconds, at an ambient temperature of 25℃, full specifications within 2 mintues
CO2 measurement Range	0-114 mmHg ; 0-15% ; 0-15.2 kPa
CO2 Response Time	Includes Transport time and rise time.Less than 2 seconds, at 150 ml/min sampling flow Less than 3 seconds, at 100 ml/min sampling flow Less than 4 seconds, at 50 ml/min sampling flow
CO2 Resolution	0.2 mmHg @ 0-59 mmHg ; 0.5mmHg @60-114 mmHg
CO2 Accuracy	0-40 mmHg ± 2 mmHg41-70 mmHg ± 5% of reading 71-100 mmHg ± 8% of reading 101-114 mmHg ±10% of reading Above 80 reaths per mintue ±12% of reading * Note:Gas temperature at 25℃
CO2 Stability	Short Term Drift : Drift over three hours shall not exceed 1 mmHg maximumLong term Drift : Accuracy specification will be maintained over a six hour period
CO2 Noise	RMS noise of the sensor shall be less than or equal to 0.5 mmHg at 5% CO2
Sampling Rate	100Hz
Respiration Rate Range	2 to 150 breaths per minute
Respiration Rate Accuracy	± 1 breath
Calibration	No Routine user calibration required
EtCO2 Calcuation	Method: peak of the expired CO2 waveform
Inspired CO2 Measurement	Method: Lowest reading of the CO2 waveform in the previous 20 seconds
Temperature	Operation : 0 to 40℃ ; Storage :-40 to 70℃ ; Transport :-40 to 70℃
Humidity	Operation :10 to 90 % RH, Non-condensing ; Storage :10 to 90 % RH, Non-condensing. Transport: 10 to 90 % RH, Non-condensing.
Atmospheric Perssure	Operating :400-800 mmHg ; Storage :400-800 mmHg ; Transport :400-800 mmHg
Water Resisitance	IPX4-Splash-Proof- sensor only
Voltage Requirements	5 VDC ±5% ; Ripple not to exceed 100.0mV
Power Raing	< 1.2W Typical; < 2.0 W Warm-up
Sensor Weight	< 250 g
Sensor Size	Deep*Wide*High 102*62*38mm
Cable Length	75cm

Packing & Delivery

If you are looking for nihon kohden mainstream etco2 sensor, welcome to contact our factory. As one of the leading manufacturers and suppliers in China, we'll offer you not the cheapest but competitive price and excellent service. Please rest assured to buy our quality products.
